It is a PLC control floral foam cutting machine
It keeps same speed and action with (1) belt conveyor.
A vertical cutting station (4) for vertical cutting. It can cut the floral foam
boards 1450mm*1450mm*80mm to be 1450mm*230mm*80mm and trimming two sides.
It has the de-dust system to take the dust during cutting away.
A Belt Conveyor (5) 1800mm length, 1500 width for floral foam block transport.
It is driven by an AC motor.
A vertical cutting station (6) for vertical cutting. It can cut the floral foam boards
1450mm*230mm*80mm to be 110mm*230mm*80mm and trimming two sides.
It has the de-dust system to take the dust during cutting away.
A pneumatic marking system (7) for stamp marks on the final product.
It can press down with logo molds automatic.
A Belt Conveyor (8) for final product which size is 110mm*230mm*80mm tranport out.
Technical Data
| Max. Block Size | L1450*W1450*H1200mm |
| Final Product Size | L110*W230*H80mm |
| Total Power | Approx. 9kw |
| Cutting Speed | 0~6m/min adjustable |
| Compress Air | 6 Bar |
Packing:
For the packing, there are a professional team to loading the cargo. and also, we have some long-term cooperation with the shipping agent who is rich experience of carrier. So do not worry, it can save money and safe for you.
After-sale Service:
1. Our engineers is avilable to oversea for coordinate installation, commissioning and training. Cost for flight and suitable accommodation plus USD 60 per day each person will be charged additionally.
2. Lifetime maintenance free of charge.
3. Free training course at our plant.
4. 24 hours on line service each day, free technical support.
5. Machine has been adjusted and test before delivery.
Warranty: 12 months limited warranty starting from date of delivery excluding wear parts.
shipping cost for parts to be replaced during warranty period have to be borned by the customers.
Terms of Paypent: 30% advance payment by T/T upon signing the contract
70% covered by Confirmed Irrevocable Sight L/C
